8 | Components description
116 AXH1230‐UK ﴾ENG﴿ ‐ Apollo KM
CONTROL MOVEMENT
Servicesrollerbackwards Oil to the hydraulic coupler
selected(colorredorsign“-”)
F/Rrollerforwards Themachinerunsinforwardsgear
(F)
F/Rrollerbackward The machine runs in reverse gear
(R)
Nbuttonpressed TheF/Rfunctionisdeactivatedand
themachinereturnstoneutral(N)
NOTICE
The joystick controls correspond to proportional movements of the machine.
