Components description | 8
AXH1230‐UK ﴾ENG﴿ ‐ Apollo KM 119
CODE COMPONENT ALARM
090.E4 Powersupply+5Vdc Output voltage lower than the lower limit of operation of the
Joystickandoftherotationsensor(ControlUnitMalfunction)
091.E4 Outputvoltagehigher thantheupperlimit ofoperationofthe
Joystickandoftherotationsensor(ControlUnitMalfunction)
101.E4 SWITCHJOYSTICK ENGINESTARTwithdeadmanswitchnotreleasedorbroken
110.E4 RollerJOYSTICK Redundancycontroloutoftolerance
111.E4 Atleastonesignaloutofrange
114.E4 Redundancycontroloutoftolerance
115.E4 Atleastonesignaloutofrange
118.E4 Redundancycontroloutoftolerance
119.E4 Atleastonesignaloutofrange
140.E4 LowIdleUpsolenoidvalve Output not commanded but a too high current consumption
hasbeendetected
141.E4 Output commanded but a too low current consumption has
beendetected
142.E4 Output commanded but a too high current consumption or a
shortcircuithavebeendetected
145.E4 Buttonpressedduringtheenginestarting
150.E4 Solenoidvalve
Distributor
Not commanded but a current consumption exceeding the
threshold has been detected
(ControlUnitMalfunction)
151.E4 Commanded but the control unit does not detect a current
consumption exceeding the threshold (Control Unit or
DistributorMalfunction)
152.E4 Output commanded but the control unit detects a high
consumption
(ControlUnitorDistributorMalfunction)
160.E4 Solenoidvalve
Servocontrol
Not commanded but a current consumption exceeding the
threshold has been detected
(ControlUnitMalfunction)
161.E4 Commanded but the control unit does not detect a current
consumption exceeding the threshold (Control Unit or
DistributorMalfunction)
162.E4 Output commanded but the control unit detects a high
consumption
(ControlUnitorDistributorMalfunction)
170.E4 ForwardCommand Not commanded but a current consumption exceeding the
threshold has been detected
(ControlUnitMalfunction)
172.E4 Output commanded but the control unit detects a high
consumption
(ControlUnitorDistributorMalfunction)
180.E4 ReserveCommand Not commanded but a current consumption exceeding the
threshold has been detected
(ControlUnitMalfunction)
182.E4 Output commanded but the control unit detects a high
consumption
(ControlUnitorDistributorMalfunction)
