Dieci APOLLO MINI AGRI - Page 147

Equipment | 9
AXH1230‐UK ﴾ENG﴿ ‐ Apollo KM 147
– Slightlylifttheboomandrotatethetoolholderplateupwards,makingtheequipmentadheretothetool
holder plate of the vehicle. During this operation, make sure that no person is in the vicinity of the
equipmentorthevehicleboom.
– Turnofftheengineandgetoutofthevehicle.
– Fastentheequipmentfullyloweringthelevers"1"intheclosedposition"B".
– Checkthatthelockcylinders"3"areproperlysecuredintheirseatsontheequipment"2".
– In the event that the equipment needs electrical or hydraulic connections, refer to the chapters
"Hydraulic connections [}149]”and“Electrical Connections [}155]”.
– Onceproperlyfixedthe equipment, turnonthevehicleand set the correctmodeofoperation of the
vehiclerelatedtothenewlyinstalledequipment:
– Consulttheuseandmaintenancemanualofthevehicletosetthecorrectmodeofuse.
– Check that in the cab there is the capacity diagram related to the vehicle and to the equipment just
installed.
DANGER
Do not operate without having properly secured the equipment to the plate, danger of
load and equipment falling.
Do not operate until both lock cylinders "3" are properly locked.
Use of “ISO” type plate with quick coupling
150665-4 150665-5
Toproperlyinstalltheequipmentonthe"ISO"typeplatewithquickcouplingitisnecessary(fig.1506604and
fig1506605)to:
– Placetheequipmentonaflatnotyieldingsurface,tobeabletosmoothlyengageitwiththetoolholder
plateofthevehicle.
– Refertothemanualofthevehicleinthechapterrelatedtotheuseofthequickcouplingtoopenthelock
cylinders“3”.
– Placethevehiclewiththeboomloweredparallelandcentraltothetool.Approachthetoolholderplate
totheaccessoryretractingthetelescopicboom.Thevehiclecannotextendtheboomifitiscompletely
lowered.Slightlyraisetheboomtobeabletoextendit.
– Usingthetiltingmovement,rotatethetoolholderplatedoordownward.Bringthetopoftheplateunder
thelockinghooksofthetool.
