8 | Components description
82 AXH1230‐UK ﴾ENG﴿ ‐ Apollo KM
Vertical position
Toadjusttheseatheight (fig.1504155),turn theleverto the
symbol“+” printed on this to increase the height or to the
symbol“”toreducetheheight.
150415-5
Mechanical suspension degree
To adjust the degree of suspension (fig. 1504156) turn the
knob towards “+” to soften the suspension. Turn the knob
towardsthe“”tohardenedsuspension.
150415-6
Pneumatic suspension degree *
NOTICE
The pneumatic suspension of the seat is an optional accessory.
Toadjustthepneumaticspringrate,pullknob(fig.1504157)to
letoutpressureandsoftensuspension.Pushtheknobtoadd
pressureandhardensuspension.
Pneumaticadjustmentcanonlybeperformedwiththeengine
running.
150415-7
