Digi XBee 3 ZigBee User Manual

API Operation Send Public Profile Commands with the API
Digi XBee® 3 Zigbee® RF Module
249
Frame Fields Offset
Description
Destination
endpoint
16 Set to the destination endpoint on the remote
device. (0x42 arbitrarily selected).
Cluster ID MSB
17
Set to the cluster ID that corresponds to the ZCL
command being sent. 0x0701 = Demand response
and load control cluster ID
LSB
18
Profile ID MSB
19
Set to the profile ID supported on the device. 0x0109
= Smart Energy profile ID.
LSB
20
Broadcast
radius
21 Sets the maximum number of hops a broadcast
transmission can traverse. If set to 0, the
transmission radius will be set to the network
maximum hops value.
Transmit
options
22 All bits must be set to 0.
Data
payload
ZCL
frame
header
Frame
control
23 Bitfield that defines the command type and other
relevant information in the ZCL command. For more
information, see the ZCL specification.
Transaction
sequence
number
24 A sequence number used to correlate a ZCL
command with a ZCL response. (The hardware
version response will include this byte as a sequence
number in the response.) The value 0x01 was
arbitrarily selected.
25 Since the frame control “frame type” bits are 01, this
byte specifies a cluster-specific command. Command
ID 0x00 in the Demand Response and Load Control
cluster is a Load Control Event command. For more
information, see the Smart Energy specification.
ZCL
payload
- load
control
event
data
Issuer event
ID
26
The 4-byte unique identifier.
Note The 4-byte ID is sent in little endian byte order
(0x78563412).
The event ID in this example (0x12345678) is
arbitrarily selected.
27
28
29
