Frame descriptions Register Joining Device - 0x24
Digi XBee® 3 Zigbee® RF Module
272
Frame data fields Offset Example
Key 16 0x01
17 0x23
18 0x45
Checksum 19 0x94
Example 2
A device needs to join a trust center using an install code. The link key used to join the network is
derived from the install code, which must be conveyed out of band to the trust center.
The joining node has an SH+SL of 0x0013A200 87654321.
The joining node has an I? value of 0x916720AC233734A86B809CC330B242EC23E and has DC set to 1;
this will cause KY to be ignored and use the install code to join.
The following frame should be sent to the trust center:
Frame data fields Offset Example
Start delimiter 0 0x7E
Length
MSB 1 0x00
LSB 2 0x1F
Frame type
3
0x24
Frame ID
4
0x43
64-bit registrant address
MSB 5
0x00
6
0x13
7
0xA2
8
0x00
9
0x87
10
0x65
11
0x43
LSB 12
0x21
Reserved
MSB 13 0xFF
LSB 14 0xFE
Options 15
0x01 (Key came from I?)
