Frame descriptions Register Joining Device - 0x24
Digi XBee® 3 Zigbee® RF Module
273
Frame data fields Offset Example
Key 16 0x09
17 0x16
18 0x72
19 0x0A
20 0xC2
21 0x33
22 0x73
23 0x4A
24 0x86
25 0xB8
26 0x09
27 0xCC
28 0x33
29 0x0B
30 0x24
31 0x2E
32 0xC2
33 0x3E
Checksum 34 0xA5
Example 3
A previously registered device needs to have its registration information removed so that it can no
longer securely join the network. This example only applies to a distributed trust center network (EO =
0).
The joining node has an SH+SL of 0x0013A200 54AB28D3.
Note Removing the key entry will not prevent the module from rejoining the network if it had
previously been associated.
Frame data fields Offset Example
Start delimiter 0 0x7E
Length
MSB 1 0x00
LSB 2 0x0D
