Caratteristiche tecniche
Technical specification
sezione / section
C 3
26
A
B
C
D
E
F
G
H
L
M
N
P
edizione/edition 03-03
* critical point for dynamic safety. Tightening torque tolerance must be: ± 5% Nm.
Note
For product specifications and symbols, refer to "Product specifications" (Sect. A 2).
Oil delivery drilled screw M 8x1.25 15
Intake and exhaust flange stud bolts M 8x1.25 15 LOCK 2 or THREE
BOND 1324
Intake manifold nuts M 8x1.25 23
Oil pump screws M 8x1.25 26
Casing jointing screws: 1st snug torque
final torque
M 8x1.25 19 (min. 17 max. 21)
25 (min. 22 max. 28)
GREASE B
Casing drilled screw M 8x1.25 20 GREASE B
Fixed tensioner M 8x1 20 LOCK 2 or THREE
BOND 1324
Mobile tensioner M 8x1.25 26 LOCK 2 or THREE
BOND 1324
Ground screw M 8x1.5 13
Fluid collector breather screw M 8x1.25 2.2
Stator cable bracket retaining screw M 6x1 10 LOCK 2 or THREE
BOND 1324
Starter motor screws M 6x1 10 LOCK 2 or THREE
BOND 1324
Starter idle gear pin screw M 6x1 10 LOCK 2 or THREE
BOND 1324
Generator stator retaining screws M 6x1 10 LOCK 2 or THREE
BOND 1324
Flywheel / rotor screws M 6x1 13 LOCK 2 or THREE
BOND 1324
Gearbox bearing stop plate screws M 6x1 10 LOCK 2 or THREE
BOND 1324
Head service screws (aluminium) M 6x1 3 LOCK 2 or THREE
BOND 1324
Intake manifold-fuel pump union M 6x1 2.5 LOCK 2 or THREE
BOND 1324
Bosch pick-up retaining screws M 6x1 10
Battery mount lower fastening stud bolt M 6x1 10 LOCK 2 or THREE
BOND 1324
Gearbox pawl screw M 6x1 10 LOCK 2 or THREE
BOND 1324
Inspection cover screws M 6x1 4.5 *
Rocker arm shaft cover screws M 6x1 10
Intake / exhaust valve cover screws M 6x1 10
Casing jointing screws M 6x1 10
Clutch cover screws M 6x1 10
Generator cover screws M 6x1 10
Clutch spring screws M 5x0.8 5 * GREASE A
Manifold nipple M 5x0.8 3 LOCK 2 or THREE
BOND 1324
Split belt roller flange retaining screws M 5x0.8 5 *
Cam cover plug M 5x0.8 2.5 *
Screws M 10x1.5 45
Screws M 8x1.25 25
Screws M 6x1 10
Screws M 5x0.8 5 *
Part Thread (mm) Nm tolerance ±10% Notes
