Mototelaio
Frame
sezione / section
H 1
3
A
B
C
D
E
F
G
H
L
M
N
P
edizione/edition 03-03
1 - SEMIMANUBRI
1 Tappo
2 Manopola
3 Distanziale
4 Tappo
5Vite
6 Semimanubrio sinistro
7 Semimanubrio destro
8Vite
9Anello OR
1
1
5
2
1
2
3
9
6
8
6
7
8
4
5
7
1 - HANDLEBARS
1Plug
2Twistgrip
3 Spacer
4Plug
5Screw
6 Left handlebar
7 Right handlebar
8Screw
9O-ring
Caution
Bold reference numbers in this section identify parts shown in this
exploded view diagram. These parts do not appear in the figures near the
text.
Importante
I riferimenti in grassetto all’interno di questo capitolo indicano che i
particolari richiamati non sono presenti nelle immagini a fianco del testo, ma
devono essere ricercati nella presente tavola esplosa.
