Ducati SS1000DS - Gearbox

Caratteristiche tecniche
Technical specification
sezione / section
C 1.1
10
A
B
C
D
E
F
G
H
L
M
N
P
edizione/edition 03-03
Cylinder / piston
Gearbox
Cooling system
Front wheel
Reference Standard value Max. allowed value
Cylinder Max. oval 0.03 mm
Max. taper 0.03 mm
Diameter
class A
class B
class C
88.000 mm
88.010 mm
88.020 mm
0 - 0.01 mm
0 - 0.01 mm
0 - 0.01 mm
Piston Diameter
class A
class B
class C
87.970 mm
87.980 mm
87.990 mm
0 - 0.005 mm
0 - 0.005 mm
0 - 0.005 mm
Gudgeon pin-piston
clearance
0.004 - 0.012 mm 0.025 mm
Piston-cylinder coupling
clearance
0.030 - 0.050 mm 0.12 mm
Gudgeon pin-connecting
rod clearance
0.006 - 0.028 mm 0.005 mm
Con-rod bearings-crankpin
coupling clearance
0.015 - 0.058 mm
Cylinders compression Mathesis 11-12 bar 10 bar (min.) difference
between cylinders: 2 bar
(max.)
Reference Standard value Max. allowed value
Idle gears Axial play 0.10 mm (min.)
Idle gears for 3rd and 4th
gears
Axial play 0.25 mm (max.)
Gearbox shafts Axial play 0.05 - 0.20 mm
Gearbox drum Axial play 0.10 - 0.40 mm
Gear selector fork Fork gear groove width 4.070 - 4.185 mm
Fork sliding shoe thickness 3.90 - 4.00 mm
Fork - gear clearance 0.070 - 0.285 mm 0.4 mm
Selector fork control drum Fork pin - groove clearance 0.265 - 0.425 mm 0.6 mm
Slot width 8.00 - 8.09 mm 8.19 mm
Fork pin diameter 7.665 - 7.735 mm 7.5 mm
Reference Technical specifications
Type Air cooling: heat is discharged
through the large fins of both
cylinder-head assemblies
Reference Standard value Max. allowed value
Tread min. thickness In the most worn position 2 mm
Tyre pressure Cold 2.1 bar - 2.2 Kg/sq cm
Wheel shaft eccentricity On 100 mm 0.2 mm
Wheel rim eccentricity Radial 0.8 mm 2 mm
Axial 0.5 mm 2 mm
