3 - TORQUE SETTINGS
Frame torque settings
Part Thread (mm) Nm ±10% tolerance Notes
Front sprocket chain
Front sprocket retaining screw M 5x0.8 6 * LOCK 1
Nut 186* GREASE B
Front sprocket cover screw M 6x1 6
Lighting devices
Tail light screw M 5x0.8 5
Headlamp support screw M 6x1 8
Number plate holder nut M 6x1 4
Turn indicator nut M 6x1 3.2
Number plate light nut M 5x0.8 1.5
Tail light-to-handle retaining screw M 4x0.7 2.5
Headlamp support-to-frame tube screw M 8x1.25 24
Reflector nut M 4x0.7 1
Headlamp support-to-frame screw M 6x1 9
Instruments
Connector fixing nut M 5x0.8 4
Instruments nut M 5x0.8 4
Front fork
Steering bearings ring nut M 25x1 12 GREASE A
Limit check nut M 8x1.25 18 LOCK 2 on nut thread
only
Steering plug M 20x1.5 12 GREASE D
Steering head screws for legs locking M 10x1.5 37 * GREASE B
Steering head screws for shaft locking M 8x1.25 23 * GREASE B
Bottom yoke screw M 8x1.25 20 GREASE B
1-2-1 sequence
Fork bottom end screw M 8x1.25 19 GREASE B
1-2-1 sequence
Electric System
Speed sensor screw M 6x1 10
Starter motor nut M 6x1 5 GREASE B
Key-operated switch screw M 6x1 9 LOCK 1
Right and left switch screw M 5x0.8 3.5
Horn bracket nut M 12x1 20
Cables-to-starter contactor nut M 6x1 4
Control unit retaining screw M 6x1 9
Coil unit-to-frame screw M 6x1 9
Regulator-to-frame screw M 6x1 9
Control unit mount-to-filter box nut M 5x0.8 5
Coil cable guide fixing nut M 6x1 10
Coil-to-mount retaining screw M 4x0.7 2
Starter motor / tube guide screw M 6x1 9
Front Brake
Front brake caliper screw M 10x1.5 43 * GREASE B
Front brake bleeder connector M 10x1 12
Front and rear brake disc screw M 8x1.25 25 * LOCK 2
