Caratteristiche tecniche
Technical specification
sezione / section
C 3
23
A
B
C
D
E
F
G
H
L
M
N
P
edizione/edition 03-03
Front brake master cylinder screw M 6x1 10 1-2-1 sequence
Rear Brake
Rear brake caliper plate retaining screw M 10x1.5 36 LOCK 8
Rear brake bleeder connector M 10x1 12
Rear brake master cylinder fluid reservoir
screw
M 6x1 1.5
Rear brake lever shaft M 10x1.5 29 LOCK 5
Rear brake master cylinder bracket retaining
screw
M 10x1.5 43 LOCK 5
Rear brake caliper screw M 8x1.5 24 * GREASE B
Rear brake master cylinder screw M 6x1 10
Rear brake line guide screw M 5x0.8 5
Rear Swingarm
Swingarm pivot shaft screw M 10x1.5 37 * GREASE B
Chain tensioner adjuster M 8x1.25 8 GREASE B
Tighten after wheel
shaft tightening
Chain sliding shoe screw M 6x1 6 LOCK 1
Handlebars - Clutch control
Handlebars screw M 6x1 9 * GREASE B
1-2-1 sequence
Throttle control screw M 6x1 9
Throttle control cover screw M 4x0.7 1.8
Clutch hose union M 10x1 19
Clutch transmission unit screw M 6x1 9 1(UP)-2-1 sequence
Rear Shock Absorber
Rear shock absorber-to-frame screw M 10x1.5 43 * GREASE B
Rear swingarm-to-rear shock absorber screw M 10x1.5 37 * GREASE B
Splashguard front screw M 6x1 2.5
Front and Rear Mudguards
Front mudguard screw M 6x1 3 LOCK 2
Rear mudguard screw M 6x1 3 LOCK 2
Glove compartment screw M 6x1 9
Splashguard-to-number plate holder screw M 5x0.8 2.3
Footpegs and Levers
Footpeg holder plate screw M 8x1.25 24 LOCK 2
Gearchange lever screw M 8x1.25 23 LOCK 2
Footpeg guard screws M 5x0.8 5 LOCK 2
Gear pedal shaft 5
Front and Rear Wheels
Front wheel nut M 25x1.5 63 * GREASE B
Rear wheel nut M 16x1.5 72 * GREASE B
Rear wheel cush drive shaft M 14x1.25* 46 * LOCK 8
Sprocket nut M 10x1.25 46 * LOCK 2
Fuel Tank
Fuel level sensor M 30x1.5 8 GREASE B
Fuel tank drain plug M 8x1.25 5 LOCK 6
Fuel breather tube clamp (inside tank) 1.5
Fuel lines clamp (inside tank) 2.5
Tank hinge bracket screw M 6x1 9
Part Thread (mm) Nm ±10% tolerance Notes
