Caratteristiche tecniche
Technical specification
sezione / section
C 3
24
A
B
C
D
E
F
G
H
L
M
N
P
edizione/edition 03-03
* critical point for dynamic safety. Tightening torque tolerance must be: ± 5% Nm.
Note
For product specifications and symbols, refer to "Product specifications" (Sect. A 2).
Fuel tank filler cap screw M 5x0.8 5
Fuel tank pads screw M 6x1 9
Exhaust
Exhaust pipe clamp screw M 8x1.25 23
Exhaust pipe on head fixing nut M 8x1.25 24
Stainless steel plugs on exhaust pipes 1/8 gaz 25
Exhaust silencer screw M 8x1.25 24
Bracket-on-silencer screw 23
Seat
Seat latch ring nut M 22x1.5 1 LOCK 3
Seat latch screw M 5x0.8 2.5
Air Intake Oil Breathing
Filter box screw M 6x1 9
Throttle body clamp 1.5
Filter box hose clamp 2.2
Oil breather tank pipes clamp 2.2
Pressure regulator bracket screw 5
Canister Filter
Canister mount nut 9
Canister mount screw M 6x1 2.5
Fairing
Fairing front stud bolt M 10x1.5 18 LOCK 2
Fairing rear stud bolt M 10x1.5 43 LOCK 2
Side panels front screw M 6x1 5
Fairing stud bolt screw M 6x1 9
Rear handle screw M 6x1 8 * LOCK 2
Fairing screw M 5x0.8 1.5
Front shield screw (under headlight) 1.8
Side panels rear screw M 5x0.8 1.5
Fairing jointing screw 2.5
Stand
Side stand plate screw M 10x1.5 43 LOCK 5
Side stand pivot shaft nut M 8x1.25 26 LOCK 5
Stand cable guide retaining screw on casing M 6x1 10
Stand sensor screw M 6x1 10
Frame
Engine-to-frame screw nut M 12x1.25 60* GREASE B
Oil cooler
Oil cooler nipple to cooler M 14x1.5 23
Oil cooler nipple to engine M 14x1.5 23
Oil cooler retaining screw M 6x1 9
Oil tube fitting to radiator with two o-rings M 16x1.5 32*
Oil tube fitting to casing with two o-rings M 16x1.5 32*
Part Thread (mm) Nm ±10% tolerance Notes
