Maintenance
Operating Instructions 581 - 01.0 - 05/2016 131
3. Insert the new cutting block and push to the end stop.
4. Re-tighten the screw (1).
Changing the blade
Fig. 80: Changing the blade
To change the blade:
1. Loosen the screw (4).
2. Pull the blade (3) forward and remove.
3. Insert the new blade and push to the end stop.
4. Re-tighten the screw (4).
(3) - Blade (4) - Screw
