Technical data
Operating Instructions 581 - 01.0 - 05/2016 175
11 Technical data
Data and characteristic values
Characteristics
Basic type
Double chain stitch-buttonholer or chai
n stitch-eyelet maker with
CNC step motor technology for material feeding and for rotating
the sewing mechanism.
Technical data Unit Class
Machine type 581
Stitch type Double chain stitch/
si
ngle chain stitch
Number of needles 1
Needle system 579
Needle strength [Nm] up to 125
Thread strength [Nm] 30/3 - 120/3
Stitch length [mm] 0.5 - 2
Speed maximum
[min
-1
]
2500
Speed on delivery
[min
-1
]
2000
Mains voltage [V] 1x190 - 240
Mains frequency [Hz] 50/60
Operating pressure [bar] 6
Length [mm] 1060
Width [mm] 750
Height [mm] 1050
