Operation
Operating Instructions 581 - 01.0 - 05/201638
Fitting clamping plates
Fig. 26: Fitting clamping plates
To fit the clamping plates:
1. Push the clamping plate forward into the mounting.
2. Allow the clamping plate to engage at the back into the pin (3).
NOTICE
Property damage may occur!
Incorrectly positioned clamping plates can result in property
damage.
Position clamping plates as described.
(3) - Pin
