Programming
Operating Instructions 581 - 01.0 - 05/2016 53
Selecting a sequential number
To select the sequential number:
1. Using the button, navigate to the field Se
quential
number (4).
2. Press the button.
Th
e cursor flashes within the desired row.
3. Select the desired number using the buttons or .
4. Confirm the selection with the button.
Selecting a buttonhole
To select a buttonhole:
1. Select the buttonhole within the sequence shown using the
buttons or .
Th
e desired buttonhole is marked with a bar.
As a selection aid, the current buttonhole shape is displayed
in the Buttonhole shape (1) field and the corresponding
values are displayed in the Values (2) area.
Selecting the operating mode
To select the operating mode:
1. Use the buttons or to navigate to the field Seq
uence (3).
2. Press the button.
3. Use the button to change the operating mode.
Th
e arrows between the buttonhole shapes appear or
disappear as appropriate.
4. Confirm the selection with the button.
