Acclarix LX9 Series Diagnostic Ultrasound System User Manual
Measurements and Reports
No.
Measurement
Group
Measurement
Item
Description
Method
3 Distances
Residual urine
Residual urine
B-mode generic
measurements
BWD
Bladder Wall Descend
UD
Uterine Descent Max
RAD
Rectal Ampulla Descent Max
Rectocele Depth
Rectocele Depth
Anal rectum
Angle
Anal rectum Angle
LH Area
Levator Hiatus Area
LH AP Diam
Anterior and posterior
Diameter of Levator Hiatus
LH Lateral Diam
Levator Hiatus Lateral Diam
LUG
Leavator urethra gap
Section 2: Doppler Measurements
2.1
Ovary A
PS
ED
RI
PI
PS,ED,RI,S/D
Time
HR
Auto Trace
Manual Trace
Spline Trace
Ovary Artery
Doppler generic
measurements
2.2
Ut. A
Uterine Artery
*The measurement method including 1 Distance, 2 Distances and 3 Distances can be switched by the
Tool Options paddle key.
8.2.2.1. eFollicle Measurement
eFollicle measurement is to automatically detect the follicles on a B-mode image and analyze their
shape and volume. The shape and volume of ovary can also be measured simultaneously.
Note:
1. eFollicle measurement is an optional feature. It is controlled by License.
2.eFollicle measurement is only available under the GYN or IVF exam preset.
3.eFollicle measurement is only available on frozen image.
1. The result of eFollicle measurement is for reference only. The measurement accuracy can be
affected by the image quality. Always confirm the detection of follicles/ovary by visual inspection
before storing the results in the worksheet and report. If the result is in doubt, manual or other
effective methods should be applied to verify the correctness.
Caution
