Acclarix LX9 Series Diagnostic Ultrasound System User Manual
Measurements and Reports
No.
Measurement
Group
Measurement
Item
Description
Method
Motion
Aa Lateral
Mitral Valve Lateral Late Diastolic
Motion
2.17
HR
Heart Rate
HR in Doppler
generic
measurements
2.18
QP/Qs
LVOT Diam
Left ventricular outflow tract
Diameter
Doppler generic
measurements
LVOT VTI
Left ventricular outflow tract
Velocity Time Integral
RVOT Diam
Right ventricular outflow tract
Diameter
RVOT VTI
Right ventricular outflow tract
Velocity Time Integral
Section 3: M-mode Measurements
3.1
LV/RV
RVAWd
Right Ventricular Anterior Wall
Thickness at End-diastole
M-mode generic
measurements
RVIDd
Right Ventricular Internal
Diameter at end-diastole
LVIDd
Left Ventricular Internal Diameter
at end-diastole
LVIDs
Left Ventricular Internal Diameter
at End-systole
3.2
LV Study
IVSTd
Interventricular Septal Thickness
at End-diastole
LVIDd
Left Ventricular Internal Diameter
at End-diastole
LVPWd
Left Ventricular Posterior Wall
Thickness at End-diastole
IVSTs
Interventricular Septal Thickness
at End-systole
LVIDs
Left Ventricular Internal Diameter
at End-systole
LVPWs
Left Ventricular Posterior Wall
Thickness at End-systole
3.3
Time
LVET
Left Ventricular Ejection Time
LV PEP
Left Ventricular Pre-ejection
Period
