Acclarix LX9 Series Diagnostic Ultrasound System User Manual
Measurements and Reports
No.
Measurement
Group
Measurement
Item
Description
Method
RV PEP
Right Ventricular Pre-ejection
Period
3.4
AV
AV Cusp Sep
Aortic Valve Cusp Separation
3.5
MV(Mitral
Valve)
E-F Slope
Mitral Valve E-F slope
EPSS
E point septal separation
MV D-E Exc
Mitral Valve DE Wave Amplitude
MV D-E Slope
Mitral Valve D-E Slope
MV E-E SEP
Mitral Valve E-E Separation
MV A-C Interval
Mitral Valve A-C Interval time
MAPSE
Mitral Annular Plane Systolic
excursion
3.6
TV
TAPSE
Tricuspid Annular Plane Systolic
excursion
3.7
LA/Ao
LA
Left Atrium diameter
AoD
Aortic root diameter
RVOT Diam
Right Ventricular outflow tract
diameter
3.8
LVM(Cube)
IVSTd
Interventricular Septal Thickness
at End-diastole
LVIDd
Left Ventricular Internal Diameter
at End-diastole
LVPWd
Left Ventricular Posterior Wall
Thickness at End-diastole
3.9
HR
Heart rate
3.10
IVC-CI
Inferior Vena Cava max diameter /
Inferior Vena Cava min diameter
8.2.4.1. Simpson’s Method of Disks (MOD)
Simpson‟s MOD is a method used to calculate LV diastolic and systolic volumes and ejection fraction.
Simpson‟s MOD is available in the Cardiac presets.
To use the Simpson‟s MOD measurement:
1. Invoke the B-mode application measurement function.
2. Select LV Simpson measurement on the touch screen and then select one measurement label
from A4C Dias., A4C Sys., A2C Dias., and A2C Sys.. A single caliper will be displayed on the
image field.
3. Move the caliper and press <Set> key to position the start point A at one end of left ventricular
long axis.
