EDAN Acclarix LX9 Series User Manual

- 15 -
Acclarix LX9 Series Diagnostic Ultrasound System User Manual
Getting Started
No.
Description
No.
Description
1
21.5" Display Monitor
9
Pencil Transducer Connector
(Reserved)
2
14" Touch Screen
10
Transducer Sockets(five)
3
Coupling Gel Holder /
Gel warmer(optional)
11
Intra-cavity Transducer Holder
4
Transducer Holders
12
Handle
5
Control Panel
13
USB Port(two)
6
Physical Keyboard
14
Wheels(four)
7
Cable Holder
15
Battery Compartment
8
ECG Connector
Table 3-3 Front View Description
Press down the keyboard case on figure 3-1 to open the keyboard for editing. Push it back after
usage.
Figure 3-2 System Keyboard
