- 16 -
Acclarix LX9 Series Diagnostic Ultrasound System User Manual
Getting Started
Figure 3-3 Left View
No.
Description
No.
Description
1
Monitor support arm
2
USB port
3
Video Printer/DVD Drive(Optional)
4
System vents
Table 3-4 Left View Description
1. Ensure system vents are clear and unobstructed.
2
2
3
4
1
CAUTION
