Acclarix LX9 Series Diagnostic Ultrasound System User Manual
Getting Started
2
4
6
Figure 3-4 Rear View
No.
Description
No.
Description
1
Storage tray
2
Video Printer/DVD Drive
(Optional)
3
I/O Ports
4
Equipotential Terminal
5
AC Power Switch/Fuse
6
AC Power Socket
Table 3-5 Rear View Description
1. To facilitate the disconnection from power supply, please do not cover the AC power socket with
any object.
1
3
5
CAUTION
