Acclarix LX9 Series Diagnostic Ultrasound System User Manual
Changes the relative size of the Doppler strip compared to the
reference image. Full, Large, Med. and Small are available.
Volume adjusts the audio volume of the Doppler strip. This
can be adjusted in pre-Doppler to set the initial volume upon
invoking Doppler acquisition.
This determines if the strip mode and reference image are
imaging simultaneously or not. In Duplex mode, either the
Doppler strip or the reference image is updated continuously.
In Triplex mode, both the Doppler strip and reference image
are updated simultaneously.
Spectral Doppler supports image presets for Low Flow,
Medium Flow and High Flow.
This control is only available for linear transducers and steers
the Doppler cursor angle left or right.
This determines the Doppler transmit frequency used for
imaging.
