C
HAPTER
3
| Using the Web Interface
Navigating the Web Browser Interface
– 100 –
N
OTE
:
Users are automatically logged off of the HTTP server or HTTPS
server if no input is detected for 600 seconds.
N
OTE
:
Connection to the web interface is not supported for HTTPS using an
IPv6 link local address.
NAVIGATING THE WEB BROWSER INTERFACE
To access the web-browser interface you must first enter a user name and
password. The administrator has Read/Write access to all configuration
parameters and statistics. The default user name and password for the
administrator is “admin.”
HOME PAGE When your web browser connects with the switch’s web agent, the home
page is displayed as shown below. The home page displays the Main Menu
on the left side of the screen and System Information on the right side. The
Main Menu links are used to navigate to other menus, and display
configuration parameters and statistics.
Figure 1: Home Page
N
OTE
:
This manual covers the ECS3510-28T and ECS3510-52T Fast
Ethernet switches. Other than the number of ports supported by these
models, there are no significant differences. Therefore nearly all of the
screen display examples are based on the ECS3510-28T. The panel
graphics for both switch types are shown on the following page.
N
OTE
:
You can open a connection to the vendor’s web site by clicking on
the Edge-Core logo.
