C
HAPTER
6
| VLAN Configuration
Protocol VLANs
– 217 –
CONFIGURING
PROTOCOL VLAN
GROUPS
Use the VLAN > Protocol (Configure Protocol - Add) page to create protocol
groups.
CLI REFERENCES
â—† "protocol-vlan protocol-group (Configuring Groups)" on page 1144
PARAMETERS
These parameters are displayed:
◆ Frame Type – Choose either Ethernet, RFC 1042, or LLC Other as the
frame type used by this protocol.
◆ Protocol Type – Specifies the protocol type to match. The available
options are IP, ARP, RARP and IPv6. If LLC Other is chosen for the
Frame Type, the only available Protocol Type is IPX Raw.
◆ Protocol Group ID – Protocol Group ID assigned to the Protocol VLAN
Group. (Range: 1-2147483647)
N
OTE
:
Traffic which matches IP Protocol Ethernet Frames is mapped to the
VLAN (VLAN 1) that has been configured with the switch's administrative
IP. IP Protocol Ethernet traffic must not be mapped to another VLAN or you
will lose administrative network connectivity to the switch. If lost in this
manner, network access can be regained by removing the offending
Protocol VLAN rule via the console. Alternately, the switch can be power-
cycled, however all unsaved configuration changes will be lost.
WEB INTERFACE
To configure a protocol group:
1. Click VLAN, Protocol.
2. Select Configure Protocol from the Step list.
3. Select Add from the Action list.
4. Select an entry from the Frame Type list.
5. Select an entry from the Protocol Type list.
6. Enter an identifier for the protocol group.
7. Click Apply.
