C
HAPTER
38
| Multicast Filtering Commands
MVR for IPv6
– 1285 –
EXAMPLE
The following shows MVR6 protocol-related statistics received:
Console#show mvr6 domain 1 statistics input
MVR6 Domain 1, MVR6 VLAN 2:
Input Statistics:
Interface Report Leave G Query G(-S)-S Query Drop Join Succ Group
--------- -------- -------- -------- ------------- -------- --------- ------
Eth 1/ 1 23 11 4 10 5 20 9
Eth 1/ 2 12 15 8 3 5 19 4
DVLAN 1 2 0 0 2 2 20 9
MVLAN 2 2 0 0 2 2 20 9
Console#
The following shows MVR6 protocol-related statistics sent:
Console#show mvr6 domain 1 statistics output
MVR6 Domain 1, MVR6 VLAN 2:
Output Statistics:
Interface Report Done G Query G(-S)-S Query Drop Group
---------- -------- -------- -------- ------------- -------- ------
Eth 1/ 1 12 0 1 0 0 0
Eth 1/ 3 5 1 4 1 0 0
DVLAN 1 7 2 3 0 0 0
MVLAN 2 7 2 3 0 0 0
Console#
Table 173: show mvr6 statistics input - display description
Field Description
Interface Shows interfaces attached to the MVR.
Report The number of IGMP membership reports received on this interface.
Leave The number of leave messages received on this interface.
G Query The number of general query messages received on this interface.
G(-S)-S Query The number of group specific or group-and-source specific query messages
received on this interface.
Drop The number of times a report, leave or query was dropped. Packets may be
dropped due to invalid format, rate limiting, packet content not allowed, or
MVR group report received
Join Succ The number of times a multicast group was successfully joined.
Group The number of MVR groups active on this interface.
Table 174: show mvr6 statistics output - display description
Field Description
Interface Shows interfaces attached to the MVR.
Report The number of IGMP membership reports sent from this interface.
Leave The number of leave messages sent from this interface.
G Query The number of general query messages sent from this interface.
