C
HAPTER
3
| Using the Web Interface
Navigating the Web Browser Interface
– 102 –
MAIN MENU Using the onboard web agent, you can define system parameters, manage
and control the switch, and all its ports, or monitor network conditions. The
following table briefly describes the selections available from this program.
Table 6: Switch Main Menu
Menu Description Page
System
General Provides basic system description, including contact information 119
Switch Shows the number of ports, hardware version, power status, and
firmware version numbers
120
IP Sets IPv4 address for management interface and gateway 564
Configure Global Sets IP address of the gateway router between this device and
management stations that exist on other network segments
564
Configure Interface Configures IP address for management access 565
Add Address Sets the IPv4 address for management access 565
Show Address Shows the IPv4 address for management access 565
Capability Enables support for jumbo frames;
shows the bridge extension parameters
122,
123
File 124
Copy Allows the transfer and copying files 124
Set Startup Sets the startup file 127
Show Shows the files stored in flash memory; allows deletion of files 128
Automatic Operation Code Upgrade Automatically upgrades operation code if a newer version is
found on the server
129
Time 133
Configure General
Manual Manually sets the current time 133
SNTP Configures SNTP polling interval 134
NTP Configures NTP authentication parameters 135
Configure Time Server Configures a list of SNTP servers 136
Configure SNTP Server Sets the IP address for SNTP time servers 136
Add NTP Server Adds NTP time server and index of authentication key 137
Show NTP Server Shows list of configured NTP time servers 137
Add NTP Authentication Key Adds key index and corresponding MD5 key 138
Show NTP Authentication Key Shows list of configured authentication keys 138
Configure Time Zone Sets the local time zone for the system clock 140
Console Sets console port connection parameters 141
Telnet Sets Telnet connection parameters 143
CPU Utilization Displays information on CPU utilization 144
Memory Status Shows memory utilization parameters 145
Reset Restarts the switch immediately, at a specified time, after a
specified delay, or at a periodic interval
146
