C
HAPTER
22
| Remote Monitoring Commands
– 795 –
â—† If the current value is less than or equal to the falling threshold, and
the last sample value was greater than this threshold, then an alarm
will be generated. After a falling event has been generated, another
such event will not be generated until the sampled value has risen
above the falling threshold, reaches the rising threshold, and again
moves back down to the failing threshold.
EXAMPLE
Console(config)#rmon alarm 1 1.3.6.1.2.1.16.1.1.1.6.1 15 delta
rising-threshold 100 1 falling-threshold 30 1 owner mike
Console(config)#
rmon event This command creates a response event for an alarm. Use the no form to
remove an event.
SYNTAX
rmon event index [log] | [trap community] | [description string] |
[owner name]
no rmon event index
index – Index to this entry. (Range: 1-65535)
log – Generates an RMON log entry when the event is triggered.
Log messages are processed based on the current configuration
settings for event logging (see "Event Logging" on page 739).
trap – Sends a trap message to all configured trap managers (see
the snmp-server host commaND).
community – A password-like community string sent with the trap
operation to SNMP v1 and v2c hosts. Although this string can be set
using the rmon event command by itself, it is recommended that
the string be defined using the snmp-server community command
prior to using the rmon event command. (Range: 1-127 characters)
string – A comment that describes this event.
(Range: 1-127 characters)
name – Name of the person who created this entry.
(Range: 1-127 characters)
DEFAULT SETTING
None
COMMAND MODE
Global Configuration
COMMAND USAGE
â—† If an event is already defined for an index, the entry must be deleted
before any changes can be made with this command.
