C
HAPTER
36
| Class of Service Commands
Priority Commands (Layer 3 and 4)
– 1170 –
COMMAND MODE
Privileged Exec
COMMAND USAGE
This map is only used when the QoS mapping mode is set to “DSCP” by the
qos map trust-mode command, and the ingress packet type is IPv4.
EXAMPLE
The ingress DSCP is composed of “d1” (most significant digit in the left
column) and “d2” (least significant digit in the top row (in other words,
ingress DSCP = d1 * 10 + d2); and the corresponding Internal DSCP and
drop precedence is shown at the intersecting cell in the table.
Console#show qos map dscp-mutation interface ethernet 1/5
Information of Eth 1/5
DSCP mutation map.(x,y),x: PHB,y: drop precedence:
d1: d2 0 1 2 3 4 5 6 7 8 9
-----------------------------------------------------------------
0 : (0,0) (0,1) (0,0) (0,3) (0,0) (0,1) (0,0) (0,3) (1,0) (1,1)
1 : (1,0) (1,3) (1,0) (1,1) (1,0) (1,3) (2,0) (2,1) (2,0) (2,3)
2 : (2,0) (2,1) (2,0) (2,3) (3,0) (3,1) (3,0) (3,3) (3,0) (3,1)
3 : (3,0) (3,3) (4,0) (4,1) (4,0) (4,3) (4,0) (4,1) (4,0) (4,3)
4 : (5,0) (5,1) (5,0) (5,3) (5,0) (5,1) (6,0) (5,3) (6,0) (6,1)
5 : (6,0) (6,3) (6,0) (6,1) (6,0) (6,3) (7,0) (7,1) (7,0) (7,3)
6 : (7,0) (7,1) (7,0) (7,3)
Console#
show qos map
phb-queue
This command shows internal per-hop behavior to hardware queue map.
SYNTAX
show qos map phb-queue interface interface
interface
ethernet unit/port
unit - Unit identifier. (Range: 1)
port - Port number. (Range: 1-28/52)
COMMAND MODE
Privileged Exec
EXAMPLE
Console#show qos map phb-queue interface ethernet 1/5
Information of Eth 1/5
PHB Queue Map:
PHB: 0 1 2 3 4 5 6 7
-------------------------------------------------------
Queue: 1 0 0 1 2 2 3 3
Console#
