C
HAPTER
38
| Multicast Filtering Commands
MVR for IPv4
– 1250 –
DEFAULT SETTING
No profiles are defined
COMMAND MODE
Global Configuration
COMMAND USAGE
â—† Use this command to statically configure all multicast group addresses
that will join the MVR VLAN. Any multicast data associated an MVR
group is sent from all source ports to all receiver ports that have
registered to receive data from that multicast group.
â—† The IP address range from 224.0.0.0 to 239.255.255.255 is used for
multicast streams. MVR group addresses cannot fall within the reserved
IP multicast address range of 224.0.0.x.
â—† IGMP snooping and MVR share a maximum number of 1024 groups.
Any multicast streams received in excess of this limitation will be
flooded to all ports in the associated domain.
EXAMPLE
The following example maps a range of MVR group addresses to a profile:
Console(config)#mvr profile rd 228.1.23.1 228.1.23.10
Console(config)#
mvr proxy-
query-interval
This command configures the interval at which the receiver port sends out
general queries. Use the no form to restore the default setting.
SYNTAX
mvr proxy-query-interval interval
no mvr proxy-query-interval
interval - The interval at which the receiver port sends out general
queries. (Range: 2-31744 seconds)
DEFAULT SETTING
125 seconds
COMMAND MODE
Global Configuration
COMMAND USAGE
This command sets the general query interval at which active receiver
ports send out general queries. This interval is only effective when proxy
switching is enabled with the mvr proxy-switching command.
