C
HAPTER
39
| LLDP Commands
– 1298
lldp dot1-tlv
vlan-name
This command configures an LLDP-enabled port to advertise its VLAN
name. Use the no form to disable this feature.
SYNTAX
[no] lldp dot1-tlv vlan-name
DEFAULT SETTING
Enabled
COMMAND MODE
Interface Configuration (Ethernet, Port Channel)
COMMAND USAGE
This option advertises the name of all VLANs to which this interface has
been assigned. See "switchport allowed vlan" on page 1126 and "protocol-
vlan protocol-group (Configuring Interfaces)" on page 1144.
EXAMPLE
Console(config)#interface ethernet 1/1
Console(config-if)#no lldp dot1-tlv vlan-name
Console(config-if)#
lldp dot3-tlv link-agg This command configures an LLDP-enabled port to advertise link
aggregation capabilities. Use the no form to disable this feature.
SYNTAX
[no] lldp dot3-tlv link-agg
DEFAULT SETTING
Enabled
COMMAND MODE
Interface Configuration (Ethernet, Port Channel)
COMMAND USAGE
This option advertises link aggregation capabilities, aggregation status of
the link, and the 802.3 aggregated port identifier if this interface is
currently a link aggregation member.
EXAMPLE
Console(config)#interface ethernet 1/1
Console(config-if)#no lldp dot3-tlv link-agg
Console(config-if)#

Table of Contents

Other manuals for Edge-Core ECS3510-52T

Questions and Answers:

Edge-Core ECS3510-52T Specifications

General IconGeneral
ModelECS3510-52T
Switching Capacity104 Gbps
Forwarding Rate77.4 Mpps
MAC Address Table Size16K
Jumbo Frames9K Bytes
Ports48 x 10/100/1000BASE-T
VLANs4K
ManagementSNMP
Power Supply100-240V AC, 50-60Hz
Dimensions (W x D x H)440 x 44 mm
Operating Temperature0°C to 45°C
Storage Temperature70°C
