C
HAPTER
5
| Interface Configuration
Trunk Configuration
– 178 –
N
OTE
:
Configuring LACP settings for a port only applies to its administrative
state, not its operational state, and will only take effect the next time an
aggregate link is established with that port.
N
OTE
:
Configuring the port partner sets the remote side of an aggregate
link; i.e., the ports on the attached device. The command attributes have
the same meaning as those used for the port actor.
WEB INTERFACE
To configure the admin key for a dynamic trunk:
1. Click Interface, Trunk, Dynamic.
2. Select Configure Aggregator from the Step list.
3. Set the Admin Key and timeout mode for the required LACP group.
4. Click Apply.
Figure 50: Configuring the LACP Aggregator Admin Key
To enable LACP for a port:
1. Click Interface, Trunk, Dynamic.
2. Select Configure Aggregation Port from the Step list.
3. Select Configure from the Action list.
4. Click General.
5. Enable LACP on the required ports.
6. Click Apply.
