C
HAPTER
12
| VoIP Traffic Configuration
Configuring VoIP Traffic Ports
– 304 –
time should be added to the overall aging time. For example, if you
configure the MAC address table aging time to 30 seconds, and the
voice VLAN aging time to 5 minutes, then after 5.5 minutes, a port will
be removed from voice VLAN when VoIP traffic is no longer received on
the port. Alternatively, if you clear the MAC address table manually,
then the switch will also start counting down the Remaining Age.
WEB INTERFACE
To configure VoIP traffic settings for a port:
1. Click Traffic, VoIP.
2. Select Configure Interface from the Step list.
3. Configure any required changes to the VoIP settings each port.
4. Click Apply.
Figure 149: Configuring Port Settings for a Voice VLAN
