C
HAPTER
14
| Basic Administration Protocols
Connectivity Fault Management
– 548 –
and some other MA y, at a higher maintenance level, and associated
with at least one of the VID(s) also in MA x, does have a MEP
configured on the bridge port.
â–
VIDS – MA x is associated with a specific VID list
13
, an MEP is
configured facing inward (up) on this MA on the bridge port, and
some other MA y, associated with at least one of the VID(s) also in
MA x, also has an Up MEP configured facing inward (up) on some
bridge port.
â–
EXCESS_LEV – The number of different MD levels at which MIPs are
to be created on this port exceeds the bridge's capabilities.
â–
OVERLAP_LEV – A MEP is created for one VID at one maintenance
level, but a MEP is configured on another VID at an equivalent or
higher level, exceeding the bridge's capabilities.
◆ MA Name – The maintenance association for this entry.
WEB INTERFACE
To show CFM continuity check errors:
1. Click Administration, CFM.
2. Select Show Information from the Step list.
3. Select Show Continuity Check Error from the Action list.
Figure 315: Showing Continuity Check Errors
13. This definition is based on the IEEE 802.1ag standard. Current software for this switch
only supports a single VLAN per MA. However, since it may interact with other devices
which support multiple VLAN assignments per MA, this error message may be reported.
