C
HAPTER
14
| Basic Administration Protocols
OAM Configuration
– 557 –
◆ Packets Received – The number of loop back frames received during
the last loop back test on this interface.
◆ Loss Rate – The percentage of packets transmitted for which there
was no response.
WEB INTERFACE
To display the results of remote loop back testing for each port for which
this information is available:
1. Click Administration, OAM, Remote Loop Back.
2. Select Show Test Result from the Action list.
Figure 321: Displaying the Results of Remote Loop Back Testing
