C
HAPTER
15
| IP Configuration
Using the Ping Function
– 560 –
COMMAND USAGE
◆ Use the ping command to see if another site on the network can be
reached.
◆ The following are some results of the ping command:
■
Normal response - The normal response occurs in one to ten
seconds, depending on network traffic.
■
Destination does not respond - If the host does not respond, a
“timeout” appears in ten seconds.
■
Destination unreachable - The gateway for this destination indicates
that the destination is unreachable.
■
Network or host unreachable - The gateway found no corresponding
entry in the route table.
WEB INTERFACE
To ping another device on the network:
1. Click IP, General, Ping.
2. Specify the target device and ping parameters.
3. Click Apply.
Figure 322: Pinging a Network Device
