C HAPTER 17 | Multicast Filtering
Multicast VLAN Registration for IPv4
– 647 –
To show the configured MVR group address profiles:
1. Click Multicast, MVR.
2. Select Configure Profile from the Step list.
3. Select Show from the Action list.
Figure 387: Displaying MVR Group Address Profiles
To assign an MVR group address profile to a domain:
1. Click Multicast, MVR.
2. Select Associate Profile from the Step list.
3. Select Add from the Action list.
4. Select a domain from the scroll-down list, and enter the name of a
group profile.
5. Click Apply.
Figure 388: Assigning an MVR Group Address Profile to a Domain
To show the MVR group address profiles assigned to a domain:
1. Click Multicast, MVR.
2. Select Associate Profile from the Step list.
3. Select Show from the Action list.

Edge-Core ECS3510-52T Specifications

General

Model	ECS3510-52T
Switching Capacity	104 Gbps
Forwarding Rate	77.4 Mpps
MAC Address Table Size	16K
Jumbo Frames	9K Bytes
Ports	48 x 10/100/1000BASE-T
VLANs	4K
Management	SNMP
Power Supply	100-240V AC, 50-60Hz
Dimensions (W x D x H)	440 x 44 mm
Operating Temperature	0°C to 45°C
Storage Temperature	70°C
