Exhaust silencer mounting assembly
M588-08-880 Issue D
Table 51 - M58808009 horizontal silencer mount - 100 ctr check list
Item Qty Description Check
1 1 Drain valve assembly 
2 1 NW32/40 clamping ring 
3 1 NW40 trapped O-ring - Viton 9830 / PTFE 
4 2 GXS raised support - 100 ctr 
5 3 M10 spring washer - nickel plated mild steel 
7 3 M10 full nut - nickel plated mild steel 
8 2 M10 x 30 hex head screw - nickel plated mild steel 
9 4 M16 spring washer - nickel plated mild steel 
10 8 M16 washer normal - nickel plated mild steel 
11 4 M16 full nut - nickel plated mild steel 
12 4 M16 x 45 hex head screw - nickel plated mild steel 
13 1 M10 x 35 hex head screw - nickel plated mild steel 
14 1 Silencer brace - 100 ctr 
15 1 Silencer mounting - 100 ctr 
16 4 M8 x 25 hex head screw - nickel plated mild steel 
16 6 M10 washer normal - nickel plated mild steel 
17 4 M8 washer normal - nickel plated mild steel 
18 4 M8 spring washer - nickel plated mild steel 
