Exhaust silencer mounting assembly
Table 53 - M59838009 horizontal silencer mount - 150 ctr check list
Item QTY Description Check
1 1 Drain valve assembly 
2 1 NW50 clamping ring 
3 1 NW50 trapped O-ring - Viton / stainless steel 
4 2 GXS raised support - 150 ctr 
5 3 M10 spring washer - nickel plated mild steel 
6 6 M10 washer normal - nickel plated mild steel 
7 3 M10 nut full - nickel plated mild steel 
8 2 M10 x 30 hex head screw - nickel plated mild steel 
9 1 Silencer brace - 150 ctr 
10 4 M16 spring washer - nickel plated mild steel 
11 8 M16 washer normal - nickel plated mild steel 
12 4 M16 full nut - nickel plated mild steel 
13 4 M16 x 45 hex head screw - nickel plated mild steel 
14 1 M10 x 35 hex head screw - nickel plated mild steel 
15 1 Silencer mounting - 150 ctr 
16 4 M8 x 25 hex head screw - nickel plated mild steel 
17 4 M8 washer normal - nickel plated mild steel 
18 4 M8 spring washer - nickel plated mild steel 
