Exhaust silencer mounting assembly
M588-08-880 Issue D
Figure 55 - M59808151 rear silencer horizontal mount - 150 ctr
* Silencer supplied separately.
Table 54 - M59808151 rear silencer horizontal mount - 150 ctr check list
Item QTY Description Check
1 1 Drain valve assembly 
21Silencer support - horizontal rear 150 ctr 
3 1 Silencer support side bracket - horizontal rear 150 ctr 
4 1 NW50 full nipple - stainless steel 
5 7 M8 spring washer - stainless steel 
6 8 M8 washer normal - stainless steel 
7 8 M8 x 20 hex head screw - stainless steel 
