Override Discrete I/O
The OVERRIDE DISCRETE I/O screens allow discrete Inputs and Outputs to be simulated whenever the
compressor is stopped (some channels are not assigned). Any overridden channels will be restored to normal
when the compressor is started.
The following table lists the various parameters displayed on the screen.
PARAMETER DEFINITION
CH The discrete channel number.
NAME The name of the discrete signal.
I/O Shows whether the discrete is an input or an output.
STATE The current state of the discrete override. AUTO indicates the output is in automatic
control, OFF indicates that the output is de-energized, and ON indicates that the output
is energized.
Override Discrete I/O Rack 1A Screen
Override Discrete I/O Rack 1B Screen
Override Discrete I/O Rack Definitions
