Intermediate Pressure Setpoints (Two Stage only) Option
The INTERMEDIATE PRESSURE SETPOINTS screen allows the operator to set acceptable ranges for the
intermediate pressure, and is only visible on the two stage compressor. An example of the screen is shown below.
The following table lists the data entry fields and a description of their purposes.
TERM DEFINITION RANGE
HIGH FAILURE The compressor is failed (stopped) when the Intermediate
Pressure exceeds this value. 0 - 225 PSIG
HIGH ALARM The Viltech reports an alarm to the operator when the
Intermediate Pressure exceeds this value. 0 - 225 PSIG
LOW ALARM The Viltech will report an alarm to the operator when the
Intermediate Pressure is below this value. 0 - 225 PSIG
LOW FAILURE The compressor will be failed (stopped) when the
Intermediate Pressure is below this value. 0 - 225 PSIG
Intermediate Pressure Setpoints
Intermediate Pressure Definitions
