Lead List
The sequencer lead list defines the order that the compressors will be added or removed. The “NONE”
selection is used to allow the operator to remove a compressor from the lead list. The user should make sure
no duplicate entries exist in the lead list and that no two sequencers contain the same compressor at the
same time. Two lead lists are now provided as a standard in most new control systems. Lead List A or B may
be selected manually or scheduled along with the sequencer control setpoint.
The following table lists the various parameters displayed on the sequencers lead list screen.
TERM DEFINITION RANGE
LEAD LIST A The order of compressors in the A lead list. Selectable
LEAD LIST B The order of compressors in the B lead list. Selectable
CURRENT ACTIVE Allows the user to select the Lead List to be Selectable
LEAD LIST used by the sequencer. The new lead list will
effect when the screen is saved.
Sequencer Lead Screen Definitions
Sequencer Lead List Screen
