72
Capacity Setpoints
The CAPACITY SETPOINTS screen allows the operator to set acceptable ranges for minimum Capacity
and Ramp Start Parameters as shown in the following example.
The following table lists the data entry fields and a description of their purposes.
TERM DEFINITION RANGE
MINIMUM CAPACITY The minimum allowable capacity of the compressor when
running. 0 - 100 PCT
RAMP START DELAY The amount of time after startup that Capacity Limiting will
take place. 0-60 MIN
RAMP START ENABLE Allows Capacity Ramp Start to be enabled or disabled. ENABLE/
DISABLE
Capacity Setpoint Definitions
Capacity Setpoint Screen
Capacity Setpoint Screen
