The following table lists the various parameters displayed on the screen.
PARAMETER DEFINITION
CH The discrete channel number
NAME The name of the discrete signal.
I/O Shows whether the discrete is an input or an output.
STATE The current state of the discrete signal.
View Analogs
The VIEW ANALOG Inputs screen can be viewed by the operator and will be displayed on a screen similar to the
following example.
Discrete I/O Rack 1B Screen
Discrete I/O Rack Definitions
Analog Inputs Screen (Channels 1-8)
To Next Page
