Oil Pressure Setpoints
The OIL PRESSURE SETPOINTS screen allows the operator to set acceptable ranges for the oil pressure
parameter to allow the Viltech to identify when the value is out of range. An example of the screen is shown
below.
The following table lists the data entry fields and a description of their purpose.
TERM DEFINITION RANGE
LOW ALARM The Viltech will report an alarm to the operator when
the Oil Pressure is below this value 20 - 200 PSIG
LOW FAILURE The compressor will be failed (stopped) when the
Oil Pressure is below this value. 20 - 200 PSIG
NOTE: The Oil Pressure on a RECIP Compressor is computed as the differential between the Oil Pressure Sensor and
Suction Pressure.
Oil Pressure Setpoints Screen
Oil Pressure Setpoints Definitions
