73
Scheduling
The SCHEDULING function allows the user to create and modify schedules to control the changing of Suction
Pressure or Process Temperature Setpoints based on the day of the week and time of day. The following sections
will describe the various screens associated with this function.
Scheduling
1. CONTROL
2. ACTIVE GROUP
3. ACTIVE SCHED
4. WEEKLY SCHED
5. DAILY SCHED
Control
The CONTROL screen allows the user to determine if equipment operation will be controlled by predefined schedules.
An example of this screen is shown below.
The following table lists the data entry fields and a description of their purposes.
TERMS DEFINITION RANGE
SCHEDULING Allows the Setpoint Scheduling feature to be enabled or disabled ENABLED/DISABLE
Scheduling Control Screen
Scheduling Definition
