Process Temperature Control Group
The PROCESS TEMPERATURE CONTROL GROUP screen is used to set-up the Process Temperature control
parameters when the Process Temperature Control option is enabled.
TERM DEFINITION RANGE
CUT-IN Cut-in Setpoint. If Automatic or Auto-Remote mode is selected,
Auto Start/Stop is enabled, the compressor is on-line, and the process
temperature rises above the Cut-in Setpoint, the compressor will start. -58: 122 DEGF
CONTROL Control Setpoint. In the Automatic or Auto-Remote mode of operation
the compressor is loaded or unloaded as required to maintain the Control
Set-point. -58: 122 DEGF
CUT-OUT Cut-out Setpoint. If Automatic or Auto-Remote mode is selected, Auto
Start/Stop is enabled, the compressor is running, and the process temperature
falls below the Cut-out Setpoint, the compressor will stop. -58: 122 DEGF
LOW ALARM An alarm is reported when the Process Temperature falls below the low
alarm setpoint. -58: 122 DEGF
LOW FAILURE A failure is reported and the compressor is shutdown when the Process\
Temperature falls below the low failure setpoint. -58: 122 DEGF
Process Temperature Definitions
Process Temperature Control Group
