Weekly Schedule
The WEEKLY SCHEDULE screen is used to define which of the seven available daily schedules is to be
assigned to each day of the week as shown in the following example screen.
The following table lists the data entry fields and a description of their purposes.
TERM DEFINITION RANGE
DAYS OF THE WEEK The daily schedule assigned to that specific day of the week. SCH1 - SCH7
Weekly Schedule Screen
Weekly Schedule Definitions
Daily Schedule
The DAILY SCHEDULE function is used to define the times at which to change control setpoints for
each of the seven available daily schedules. The first screen upon entering the Daily Schedule
function is an access screen, which prompts the user to enter a number from one to seven to view the
corresponding Daily Schedule.
Daily Schedule Screen
